Technical data
| Item information | Value |
|---|---|
| Control protocol: | Art-Net / sACN (E1.31) / DMX512 |
| Ambient operating temperature: | -20 °C to +70 °C |
| Enclosure: | ABSABS with conformal coating |
| Input voltage: | 5–24 V DC (controller only) |
| Pixel outputs: | 4 |
| Ethernet ports: | 1 × 10/100 Mbit/s |
| Auxiliary port: | RS485 (DMX in/out) |
| Card slot: | microSD (card not included) |
| Mounting: | Flat surface or DIN rail (kit sold separately) |
| Pixels per output: | up to 1,020 RGB / 768 RGBW |
| Universes: | 24 |
| Dimensions: | 115 × 86 × 33 mm |
| Show storage: | microSD, SHOWTime™ up to 25 triggers |
| Image processing: | Gamma correction and dithering |
| Power consumption: | max. 2.5 W |
| Weight: | 0.1 kg |
| : | Indoors by defaultIndoors by default; with conformal coating also outdoors when additionally mounted inside a weatherproof enclosure |
| Pixel power supply: | separate power injection |
| WEEE-Reg.-Nr.: | DE 32487762 |
| Shipping weight: | 0,50 kg |
