MADRIX 5 start licence

SKU: LCO-1066-01

Category: software

GTIN: 4260263425088

MADRIX is a powerful, easy-to-use, and award-winning LED lighting control software and allows you to realize all kinds of different LED projects and lighting designs.

A normal PC/laptop can be used for professional LED control

69,99 €

incl. 19% VAT , plus

Choose tax zone / country of delivery

Available immediately

piece

Available immediately

Includes 1 license for the software MADRIX

Provides the output for 2 x 512 DMX channels and 64 x 64 DVI voxels (corresponds to 2 DMX universes / 1024 DMX channels and 4096 DVI voxels)

The license activates a USB dongle (KEY), with which the software can be operated

Can be used in parallel with other MADRIX licenses

Can be upgraded to higher licenses (up to MADRIX maximum)

Supports many industry protocols and communication standards for direct connection to your LEDs and LED controllers (incl. DMX512, Art-Net, Streaming ACN (E1.31), Philips Color Kinetics (KiNET), Insta/ROBE protocols, Philips Hue, SPI via Nebula etc.)

Allows mapping in 2D (pixel mapping) as well as real, spatial 3D (voxel mapping)

The software generates unique effects, visuals, and animations live and in real time

No additional content is required

Already includes a multitude of stock effects that are fully customizable (in speed, color, shape, direction, size, movement, position, brightness, etc.)

TRI effects will be based on existing MADRIX Effects. On top, you can trigger them manually using DMX-IN or MIDI

The audio output of videos can be put out directly

CSV fixture list import possible

Analyzes incoming audio signals Sound2Light and Music2Light in real time

New lighting scenes can easily be created in seconds

Supports media server features also: Conveniently load and play back images, pictures, and videos as well as live signal capturing, screen capturing, scrolling text (ticker), and more

Variety of options to combine visuals and graphical elements (layers, mix modes, filters, etc.)

256 x 256 Storage Places to organize and store effects

DJ-like operation with 2 decks (Left/Right) and a crossfader

3 real-time previews to show your visual effects in advance (incl. 2D/3D, zoom, rotation)

Controls up to 4 color channels per pixel/voxel (e.g. 1-channel, 2-channel, RGB, RGBW fixtures)

Freely configurable Cue List for automated playback of a show (incl. time, date, duration, etc.)

Supports Time Code from Art-Net, MIDI, SMPTE, and system time

Remote control available via DMX-IN, Art-Net Remote, MIDI-IN, HTTP (internet browser), CITP

Accompanying Fixture Editor provided including large fixture library

Includes various other tools and features (DMX Fader Tool, DMX Watcher, Matrix Generator, Patch Editor, Touch Screen window, backup system, scripting, mapping, scaling, etc.)

Supports various 3rd-party interfaces and MADRIX hardware interfaces (sold separately)

Minimum system requirements: 2.0 GHz dual-core CPU, OpenGL 2.0 graphics card (NVIDIA recommended), 2 GB RAM, 1 GB free hard disk space, 1280 x 768 screen resolution, network card, sound card, USB 2.0
